Lúbadh (Lubadh)

Instruo

Regular price $5,110.00 HKD Sale

Consisting of two identical channels Lúbadh allows you to instantly record, playback, overdub, trim down, scan through and pitch up or down any audio signal.

Inspired by the aesthetics and mechanics of early tape techniques each channel features an analogue input circuit which adds slight compression, filtering and saturation. On the first recording, the sound may appear slightly fuller and warmer,
re-recording audio back and forth will compound this effect over time allowing you to create dense tape like textures.

Lúbadh | ˈluːbɑː | verb (willow weaving) loop, link, coil, twist, bend; meander of a river, to be fond of, wrapped up in

MANUAL

QUICKSTART GUIDE

Description

Size

20HP
Depth: 42mm

Power

+12V: 250mA
–12V: 100mA

Features

2 channel looper
Tape response inspired analogue input circuit
LED display for playback speed, length and position
Nine minutes record time per channel (more than 450 feet of tape at 15ips)
Varispeed –/+ 4x speed
Link switch for dual mono functionality
Delay capabilities
Clock divider output
VCA controlled auxiliary input/output crossfading
Looping or one-shot record and playback capabilities
Load/save functionality
Capacitive touch plate for creating warble effects and stalling playhead
Included 2HP CV expander for CV over everything

Description

Consisting of two identical channels Lúbadh allows you to instantly record, playback, overdub, trim down, scan through and pitch up or down any audio signal. The two channels are normalised to each other via a feedback path allowing you to manipulate and resample audio to build up complex looping compositions. Shifting the timing of these two channels within the feedback path creates a tape delay type effect with delay times up to 3 seconds.
